Installing a Helac hydraulic rotary actuator correctly is essential to ensure its optimal performance, longevity, and safety. Helac hydraulic rotary actuators are sophisticated devices used in various heavy-duty applications, converting hydraulic pressure into precise rotary motion. This comprehensive guide will walk you through the step-by-step process of installing a Helac hydraulic rotary actuator, including preparation, assembly, timing, bleeding, and testing. Visual aids and videos are recommended throughout the process to enhance understanding.
Before installation, it's important to understand what a Helac hydraulic rotary actuator is and how it works. These actuators use helical spline technology to convert linear piston motion into powerful rotary movement. The key components include the housing, shaft, piston sleeve, seals, bearings, and end caps. The actuator's design allows it to handle high loads, resist shock, and operate reliably in harsh environments such as agriculture, construction, marine, and mining industries.
- Secure the actuator housing firmly on a slotted table or pipe vise to prevent movement during assembly.
- Ensure the workspace is clean to avoid contamination of internal components.
- Gather all necessary tools: seal installation tools, strap wrench, hex wrenches, grease gun, hydraulic oil, lithium grease, and timing markers.
- Clean all parts thoroughly using a solvent tank and dry with compressed air.
- Inspect the housing bore, shaft, piston sleeve, gear teeth, seal grooves, and bearings for wear, scratches, or damage.
- Polish minor scratches carefully to prevent seal damage.
- Replace all seals, bearings, and wear guides with new components to ensure reliability.
- Lightly oil all seals, seal grooves, bearings, and housings with clean hydraulic oil before installation.
- Using a seal tool, install exclusion seals, main pressure seals, and wear guides onto the shaft and end caps.
- Grease thrust washers with lithium grease before placing them on the shaft and end caps.
- Install O-rings and backup rings into the inner seal grooves on the end caps.
- Install piston sleeve seals carefully, noting that some seals require removal of energizer O-rings to prevent pressure trapping.
- Coat the shaft and piston sleeve with clean hydraulic oil.
- Align timing marks on the shaft and piston sleeve carefully.
- Press the piston sleeve onto the shaft, ensuring the piston ID seal slides over the shaft chamfer with a slight pop or click.
- Rotate the piston sleeve with a strap wrench to engage the gear teeth firmly.
- Confirm timing marks alignment between shaft and piston sleeve.
- Insert the assembled shaft and piston sleeve into the housing.
- Align timing marks on the housing, piston sleeve, and shaft carefully.
- Use dowel pins and a pry bar to gently compress the main pressure seal and mesh the gear teeth by rotating the shaft slightly back and forth.
- Ensure the shaft flange is flush with the housing face and timing marks line up precisely.
- Coat end cap threads with grease.
- Install end caps onto the housing, aligning marks made before disassembly.
- Insert locking pins and port plugs into the end caps.
- Torque the end caps to the recommended specification (e.g., 200 ft-lbs or 271 Nm).
- If locking pin holes are misaligned, adjust the cap position slightly or re-drill as necessary.
- After installation, reattach all safety devices such as tie rods or safety cables.
- Remove port plugs on the actuator to allow air purging.
- Connect hydraulic lines to the lower ports and vent air through the upper ports.
- Apply pressure alternately to each port to rotate the actuator fully and purge trapped air.
- Replace port plugs once air is fully purged.
- This process ensures smooth operation and prevents cavitation or erratic movement.
- Secure the actuator firmly to prevent movement during testing.
- Use a grease gun to pack seals with grease until it exhausts from the wiper seals.
- Cycle the actuator slowly 20 to 30 times to remove air and check for leaks.
- Confirm the actuator achieves the proper degrees of rotation and smooth operation.
- Conduct pressure testing using a hydraulic test gauge to check for internal leakage.
- Always wear approved eye protection and gloves when handling hydraulic components.
- Secure the actuator firmly to prevent unexpected movement during assembly and testing.
- Be cautious when releasing hydraulic pressure; sudden fluid release can cause injury.
- Maintain a clean workspace to avoid contamination that can damage seals and internal parts.
Installing a Helac hydraulic rotary actuator correctly involves meticulous preparation, precise assembly, accurate timing, thorough bleeding, and rigorous testing. Following the manufacturer's detailed service manuals and using the right tools and lubricants ensures the actuator's durability and performance. Proper installation safeguards the actuator from premature wear and operational failure, making it a reliable component in heavy-duty hydraulic systems.
Correct timing is ensured by aligning the timing marks on the shaft, piston sleeve, and housing precisely. Use a strap wrench to engage gear teeth firmly and verify alignment before final assembly. Misalignment can cause over-rotation or limited range of motion.
Use clean hydraulic oil to coat seals, bearings, and machined surfaces before installation. Lithium grease is recommended for thrust washers and other moving parts to reduce friction and wear.
Yes, performing a dry run without seals can help familiarize with gear tooth alignment and assembly steps. This practice reduces errors during final assembly and timing.
Remove upper port plugs and connect hydraulic lines to lower ports. Apply pressure alternately to each port while venting air through the open upper ports until all air is purged, then reinstall plugs.
Wear approved eye protection, secure the actuator firmly to prevent movement, and be cautious of hydraulic fluid under pressure when removing port plugs and fittings. Keep the work area clean to avoid contamination.
