The Toro 824 XL is a powerful two-stage snow blower designed for residential use, capable of handling heavy and wet snow conditions. It features a 24-inch clearing width, an 11-inch auger diameter, and a Toro Premium 252cc OHV 4-cycle engine. When it comes to maintaining or repairing your Toro 824 XL, understanding the correct size and type of belts is crucial. This article will delve into the specifics of the auger drive belt for the Toro 824 XL, including its size, replacement process, and troubleshooting tips.
The Toro 824 XL Power Throw Snowthrower is part of Toro's lineup of two-stage snow blowers, known for their reliability and efficiency in clearing snow. It is equipped with a friction disk drive system and features six forward speeds and two reverse speeds, making it versatile for various snow conditions.
- Clearing Width: 24 inches (61 cm)
- Auger Diameter: 11 inches (27.9 cm)
- Engine: Toro Premium 252cc OHV 4-cycle
- Throw Distance: Up to 45 feet (13.7 meters)
- Weight: 184 lbs (83.4 kg)
- Fuel Type: Gasoline
- Ideal Snow Depth: 12 inches (30 cm)
For the Toro 824 XL, the auger drive belt is typically a replacement part with specific dimensions and material. The belt is designed to withstand the rigors of snow blowing, including high torque and cold temperatures.
- Top Width: 1/2 inch (12.7 mm)
- Height: 5/16 inch (7.94 mm)
- Length: Inside length of 38 inches, outside length of 40 inches (96.5 cm and 101.6 cm respectively)
- Material: Dry wrapped aramid cord, which provides strength and resistance to environmental factors like humidity and high temperatures.
The original equipment manufacturer (OEM) part numbers for Toro snow blower belts can vary depending on the specific model and application. For similar models like the Toro Snowmaster 824 QXE, common OEM part numbers include 131-5967. Replacement belts are available from various suppliers, often cross-referenced with other brands for compatibility.
Replacing the auger drive belt on a Toro 824 XL involves several steps, including accessing the belt area, removing the old belt, and installing the new one. Here's a simplified guide:
1. Access the Belt Area: Remove any covers or guards to expose the belt and pulleys. This may involve unscrewing bolts or clips.
2. Release Tension: Use the tensioner to loosen the belt. This will allow you to remove the old belt more easily.
3. Remove the Old Belt: Slide the old belt off the pulleys and set it aside.
4. Install the New Belt: Place the new belt around the pulleys, ensuring it is properly seated and aligned.
5. Re-tension the Belt: Use the tensioner to tighten the new belt to the recommended tension.
6. Replace Covers: Put back any covers or guards you removed.
- Cause: Incorrect tension, worn pulleys, or misaligned belt.
- Solution: Check and adjust belt tension, inspect pulleys for wear, and ensure proper belt alignment.
- Cause: Overuse, improper installation, or excessive load.
- Solution: Inspect for signs of wear before use, ensure correct installation, and avoid overloading the snow blower.
- Cause: Obstructions in the auger or impeller, or broken shear pins.
- Solution: Inspect and clear any obstructions, and replace shear pins if necessary.
- Cause: Lack of fuel, old fuel, or spark plug issues.
- Solution: Check fuel levels, drain old fuel and refill with fresh gasoline, and replace the spark plug if necessary.
- Oil Levels: Ensure the engine has sufficient oil before each use.
- Spark Plug Condition: Check and replace the spark plug if necessary to maintain engine performance.
- Air Filter: Clean or replace the air filter to improve engine efficiency and reduce the risk of carburetor issues.
- Silicone Spray: Apply silicone spray to the chute, auger, and other snow-contacting surfaces to reduce sticking and improve snow flow[5].
- Belt Maintenance: Regularly inspect belts for signs of wear, especially after handling wet snow, as it can cause belts to weaken faster[5].
- Problem: Snow blower is difficult to maneuver or lurches forward.
- Solution: Adjust the drive cables to apply proper tension to the belt. Unclip the cable from the handle, snug up the line's threaded adjustment at the base of the machine, and reconnect the clip[4].
Before the snow season begins, perform a thorough inspection of your Toro 824 XL. Check for any worn or damaged parts, clean the machine thoroughly, and apply lubricants to moving parts to ensure smooth operation.
After the snow season, store your Toro 824 XL in a dry location. Drain the fuel tank or use a fuel stabilizer to prevent fuel degradation. Cover the machine to protect it from dust and moisture.
If your snow blower runs rough or only operates on full choke, it may indicate a carburetor issue. Cleaning the carburetor can resolve these problems. Remove the intake and inspect for dirt or debris. Use a carburetor cleaner to clean all pathways and jets[6].
The friction disk is crucial for engaging the drive system. If it shows signs of wear, such as slipping or failure to engage properly, consider replacing it. This can often resolve issues with the snow blower's ability to move forward or reverse[9].
Shear pins are designed to break when the auger encounters an obstruction, protecting the engine and other components. Keep spare shear pins on hand and replace them promptly if they break to ensure continuous operation[4].
Maintaining your Toro 824 XL snow blower involves ensuring that all components, including the auger drive belt, are in good condition. Understanding the correct size and type of belt is crucial for optimal performance and longevity of the machine. Regular checks and timely replacements can prevent breakdowns during critical snow clearing operations. Additionally, following the tips outlined above will help extend the life of your snow blower and ensure it performs well year after year.
The correct size for the auger drive belt on the Toro 824 XL is typically an inside length of 38 inches and an outside length of 40 inches, with a top width of 1/2 inch and a height of 5/16 inch.
Replace the belt when it shows signs of wear, such as cracks, fraying, or excessive stretching. Regular inspections before each snow season are recommended.
The auger drive belt is usually made from dry wrapped aramid cord, which offers strength and resistance to environmental factors like humidity and high temperatures.
While universal belts may be compatible, it's recommended to use OEM or high-quality aftermarket belts specifically designed for your model to ensure optimal performance and durability.
Proper tension is achieved when the belt is snug but not overly tight. Consult your user manual for specific tensioning guidelines.
