The Ford Coyote engine, known for its high performance and reliability, sometimes requires maintenance to ensure optimal operation. One such maintenance task is shimming hydraulic lifters. This article will guide you through the process of shimming hydraulic lifters in a Coyote motor, providing detailed instructions, tips, and insights to help you complete this task effectively.
Before diving into the shimming process, it's essential to understand what hydraulic lifters are and why they might need shimming.
Hydraulic lifters are components in the valve train of an engine that help maintain proper valve clearance. They use engine oil pressure to automatically adjust for any wear in the valve train, ensuring consistent valve operation. However, in some cases, particularly with aftermarket camshafts or when rebuilding an engine, shimming may be necessary to achieve the correct lifter preload.
Hydraulic lifters consist of a cylindrical body with an internal piston. As the camshaft lobe pushes on the lifter, oil is forced into the lifter body, causing the internal piston to extend and take up any clearance in the valve train. This self-adjusting mechanism helps maintain proper valve timing and reduces engine noise.
Lifters play a crucial role in the overall performance of your Coyote engine. They are responsible for:
1. Transferring camshaft motion to the valves
2. Maintaining proper valve clearance
3. Reducing wear on valve train components
4. Ensuring smooth and quiet engine operation
When lifters are not functioning correctly or are improperly shimmed, it can lead to a range of issues, from reduced performance to potential engine damage.
Shimming hydraulic lifters becomes necessary in the following situations:
1. Installing aftermarket camshafts with a smaller base circle
2. Rebuilding the engine with new components
3. Addressing excessive valve train noise
4. Optimizing engine performance for high-RPM operation
- Excessive ticking or tapping noise from the valve train
- Reduced engine performance, especially at higher RPMs
- Inconsistent idle or rough running
- Failed emissions test due to improper valve timing
Correct lifter preload is crucial for several reasons:
1. It ensures optimal valve timing
2. It prevents excessive wear on valve train components
3. It maintains proper oil circulation within the lifter
4. It contributes to smooth and efficient engine operation
Improper preload can lead to a range of issues, from poor performance to catastrophic engine failure in extreme cases.
Before starting the shimming process, gather the following tools and materials:
- Lifter shim kit specific to the Coyote engine
- Socket set and ratchet
- Torque wrench
- Feeler gauge set
- Clean rags
- Engine oil
- Valve cover gasket set
- Threadlocker
- Plastic calibrated bucket for oil collection
- Safety glasses and gloves
- Engine stand (optional but recommended)
- Service manual for your specific Coyote engine model
When selecting a shim kit, consider the following:
1. Compatibility with your specific Coyote engine model
2. Range of shim thicknesses available
3. Material quality (hardened steel is preferred)
4. Brand reputation and reviews from other Coyote engine owners
Investing in a high-quality shim kit can save you time and potential headaches down the road.
Begin by ensuring your work area is clean and well-lit. Remove the valve covers to access the lifters and rocker arms. It's recommended to work on one cylinder at a time to avoid confusion.
Before starting, ensure the engine is cool and disconnected from the battery. Wear safety glasses and gloves throughout the process to protect yourself from potential oil spills or debris.
If possible, position the engine on an engine stand. This will provide better access to all cylinders and make the shimming process more comfortable and efficient.
Rotate the engine until the lifters for the cylinder you're working on are on the base circle of the camshaft. This is when both valves are closed, and the lifters are at their lowest point.
Use a socket on the crankshaft pulley bolt to rotate the engine manually. Turn it clockwise to ensure proper rotation and avoid potential timing issues.
Using a feeler gauge, measure the gap between the rocker arm and the valve stem. The correct preload is typically between 0.020" and 0.040", but always refer to your specific camshaft manufacturer's recommendations.
Take multiple measurements to ensure accuracy. Even small discrepancies can affect engine performance and longevity.
Keep a detailed record of measurements for each lifter. This will help you track changes and ensure consistency across all cylinders.
Based on your measurements, select the appropriate shim thickness. Each shim will account for approximately 0.025" of adjustment. For example, if your base circle is 0.050" smaller than stock, you'll need two shims to maintain the correct lifter preload.
- Always start with the thinnest shim necessary and work your way up if needed.
- Keep shims organized to avoid confusion during installation.
- Consider using a shim organizer or labeled containers for each lifter position.
Carefully remove the rocker arm and place the selected shim(s) over the lifter. Reinstall the rocker arm and torque it to the manufacturer's specifications. Be sure to use threadlocker on the rocker arm bolts.
Ensure the shim sits flat on the lifter and doesn't interfere with the rocker arm's movement. Improper placement can lead to accelerated wear or engine damage.
Use a torque wrench to tighten the rocker arm bolts to the specified torque. Over-tightening can damage components, while under-tightening can lead to loosening during operation.
After installing the shims, recheck the preload using a feeler gauge. Make any necessary adjustments by adding or removing shims until the correct preload is achieved.
Take the time to verify each lifter's preload multiple times. This extra effort can prevent potential issues down the road.
Repeat steps 2-6 for each lifter that requires shimming. Take your time and double-check your work as you go.
Work methodically, completing one cylinder at a time. This approach helps maintain organization and reduces the risk of mistakes.
Once all lifters have been shimmed and verified, clean the valve cover mating surfaces and install new gaskets. Reinstall the valve covers and torque the bolts to the specified value.
Follow the manufacturer's recommended torque sequence when reinstalling valve covers to ensure even pressure and prevent leaks.
Before closing everything up, perform a visual inspection of all components to ensure nothing is out of place or improperly installed.
- Always use high-quality shims designed for your specific engine.
- Keep your work area clean to prevent debris from entering the engine.
- Take your time and be methodical in your approach.
- If you're unsure about any step, consult a professional mechanic.
- Document your work with photos or notes for future reference.
- Consider replacing lifters if they show signs of wear or damage.
- Use a magnetic tray to keep small parts organized during the process.
- Perform the shimming process in a well-ventilated area to avoid inhaling oil fumes.
1. Over-tightening rocker arm bolts
2. Using the wrong size or type of shims
3. Failing to properly clean components before reassembly
4. Neglecting to use new valve cover gaskets
5. Mixing up lifter positions when working on multiple cylinders
6. Forgetting to rotate the engine to check for clearance issues
7. Ignoring unusual noises or resistance during reassembly
8. Rushing through the process and skipping crucial verification steps
Correctly shimmed lifters can provide several benefits:
1. Reduced valve train noise
2. Improved engine performance, especially at high RPMs
3. Extended engine life due to reduced wear
4. Optimized valve timing for aftermarket camshafts
5. Increased fuel efficiency due to optimized valve operation
6. Better overall engine reliability and consistency
7. Potential for improved horsepower and torque output
8. Enhanced engine responsiveness and smoother operation
After completing the shimming process, it's important to follow proper maintenance procedures:
1. Change the engine oil and filter to remove any debris that may have entered the system during the shimming process.
2. Run the engine at idle for several minutes to ensure proper oil circulation and check for any unusual noises.
3. Perform a test drive, paying attention to engine performance and any potential issues.
4. Re-check valve cover bolt torque after the initial heat cycle to ensure proper sealing.
To maintain the benefits of your newly shimmed lifters:
1. Adhere to regular oil change intervals using the recommended oil grade.
2. Listen for any changes in engine noise that might indicate lifter issues.
3. Periodically check valve cover gaskets for leaks.
4. Consider rechecking lifter preload during major service intervals or if performance issues arise.
Shimming hydraulic lifters in a Coyote motor is a precise task that requires patience and attention to detail. By following this guide and taking the necessary precautions, you can successfully adjust your lifters for optimal engine performance. Remember that if you're ever in doubt, it's always best to consult with a professional mechanic or engine builder to ensure the job is done correctly.
Proper lifter shimming can significantly improve your Coyote engine's performance and longevity. While it may seem daunting at first, with the right tools, knowledge, and approach, it's a task that can be accomplished by dedicated DIY enthusiasts. However, always prioritize safety and don't hesitate to seek professional help if you encounter any difficulties during the process.
By taking the time to properly shim your hydraulic lifters, you're investing in the health and performance of your Coyote engine. The results will be evident in smoother operation, improved power delivery, and the satisfaction of knowing your engine is running at its best.
It's generally recommended to check lifter preload during regular engine maintenance or when you notice unusual valve train noise. For high-performance applications, more frequent checks may be necessary.
Yes, in most cases, you can shim hydraulic lifters without removing the camshaft. However, access may be limited, and it's crucial to work carefully to avoid damaging other engine components.
Properly shimmed lifters can improve engine performance, especially at high RPMs. However, incorrect shimming can lead to reduced performance and potential engine damage.
Yes, over-shimming can cause excessive preload, leading to increased wear and potential valve train damage. Always follow the manufacturer's recommendations and verify your measurements.
It's generally not recommended to reuse old lifter shims. New shims ensure precise measurements and better performance. Always use fresh shims when adjusting lifter preload.
